Computer Panel High Speed Saw NPC280 (2780x90mm)

Saw carriage by 2kw servo motor and moved via rack and pinion automatically moved to fit based on the width of panel, reduces travel distance. Max cutting speed up to 90m/min, backward speed up to 120m/min;

Pressure beam automatically self-adjusted according to the total height of panels, to shorten the travel range, hence higher efficiency;

Powerful software so easy to use, including managing the work process with detailed reports, simulating cutting patterns, showing any error message, printing bar code and many more advantages, also user friendly HMI, making whole machine much reliable.

- Air float feed table

- Side operation rod

- Pressure Beam

- Hand Protector

- Piano dust cover

- Side alignment

- Gripper

- Anti-dropping device

- Sawing Carriage

- Dust Collection Poart 150mmx3no.

- Auto Lubrication System

- User-friendly HMI IPC with USB ports

- Optimization software NXPareto

- Operation Software

- Label Printer & Opticut Software

TECHNICAL SPECIFICATIONS:

- Max. cutting length : 2780mm

- Max. cutting thickness : 90mm

- Main Saw Motor power : 15kw

- Main Saw Rotating speed : 3910 rpm/min

- Saw blade diameter : 380mm (Max Dia.400mm)

- Saw blade shaft diameter : 60mm

- Rotating speed : 4,300rpm/min

- Saw blade diameter : 200mm

- Saw blade shaft diameter : 45mm

- Saw carriage Motor power : 2kw

- Saw carriage Forward speed : 90m/min

- Saw carriage Backward speed : 120m/min

- Automatic feeding motor : 2kw

- Max. feeding speed : 85m/min

- IPC 15’’ Windows 7 : USB port: 4 pcs

- Air Requirement  : 0.6 MPa

- Dust extraction Diameter  : 150mm*3; 28m/min

- Power supply  : AC3P380V/50Hz

- Total power : 23.5kw

- Length *Width *Height : 6400 x 4995 x 1830mm

- Net weight  : 4800kg
