CNC 6-Sided drilling machine ND512TS
TECHNICAL DATA
- Total power : 13.87 KW
- Machine size : 3962*2222*2271 mm
- Power supply : 380V/50Hz
- Air supply : 0.6-0.7MPa
- Control system Brand : SYNTEC
- Panel size Length : 200-3,000mm
- Panel size Width : 30-1,200mm
- Panel size Thickness : 10-60mm
- Max. traveling speed (X /U）axis : 135m/min
- Max. traveling speed Y axis : 75m/min
- Max. traveling speed Z axis : 30m/min
- Max. traveling speed V axis (push) : 30m/min
- Working table Material : HPL
- Working table Table size : 1478 x 275 mm
- Working table height : 955mm
- Drilling block qty : Top 1; Bottom 1
- Vert. drills qty Top : 10
- Horiz. drills qty Top : X: 6 + Y: 4
- Vert. drills qty Bottom : 9
- Max drill diameter : 35mm
- Drill spacing : 32mm
- Rotation speed : 5000rpm
- Shank diameter : 10mm
- Drill length : 70mm
- Main spindle Top : 1
- Main spindle power : 3.5kw
- Dust collector qty : 2
- Dust collector diameter : Top 200mm×1
- Dust collector diameter : Bottom 125mm×1
- Dust collector speed : 28m/min
- Auto Tool Changer
